MBraun UV-Clean
The MBraun MB-UV-O₃ cleaner (UV-Clean) removes organic contamination from glass substrates and other UV/ozone-stable materials without residue – directly inside the inert-gas box, with no process interruption. Available as a stand-alone unit or as a fully glovebox-integrated module. The unit is used but was tested only once.
Fully automated process
Purge with CDA → UV exposure → nitrogen purge – every step configurable via the touch panel. An integrated palladium catalyst converts the ozone produced directly back into normal oxygen, so a separate fume hood is not strictly required. Status is shown via a traffic-light system right at the glove port.
| Manufacturer | MBraun |
| Model | MB-UV-O₃ cleaner (UV-Clean) |
| Function | UV/ozone surface cleaning inside the glovebox |
| Substrate size | up to 152 × 152 mm |
| UV lamp | ozone-generating Hg lamp, ~50 mW/cm² |
| Process | purge (CDA) → UV exposure → N₂ purge, configurable |
| Ozone abatement | integrated palladium catalyst (ozone → O₂) |
| Operation | touch panel, traffic-light status, weekly lamp test |
| Setup | stand-alone or glovebox-integrated |
| Condition | Used, tested only once – manuals available |
| Viewing | on site possible |
At a glance
Highlights & benefits
Residue-free removal of organic contamination
UV/ozone activation directly inside the inert-gas box
Fully automated, configurable process
Integrated palladium catalyst – no mandatory fume hood
Traffic-light status indication at the glove port
Safe: interlocked operation, UV shield, emission alarm
Applications
Ideal for
Surface activation of glass substrates
Thin-film applications
OLED manufacturing
Solar cells
Pre-treatment before further processing under inert gas
